BODY

Automatic on/off headlights
LED fog lights
LED daytime running lights
Rain-sensing variable-intermittent windshield wipers
Body-colored power and heated side mirrors with integrated turn signals roof-mounted "shark fin" antenna
Rear window wiper

WHEELS & TIRES

16 x 5.5 J aluminum alloy
185/60 R16
Temporary spare tire - T125/70 D15

EXTERIOR DIMENSIONS

Wheelbase (mm) 2,570
Track, front (mm) 1,495
Track, rear (mm) 1,485
Length (mm) 4,060
Width (mm) 1,695
Height (mm) 1,495
Minimum ground clearance, unladen (mm) 152

COMFORT & CONVENIENCE

Air conditioning climate control
Power windows with driver's one-touch-down/up feature
Cruise control with steering-wheel-mounted controls
Mazda Advanced Keyless Entry
Push button start
Tilt & telescopic steering column

STORAGE

Front cup holder
Front door storage pockets with bottle holders
Front passenger-side seatback pocket

SEATING & TRIM

5-passenger seating capacity
60/40 split fold-down rear seatback
Leather/cloth-trimmed seats
Carpet floor mats
Leather-wrapped steering wheel and shifter

AUDIO & INFOTAINMENT

7" full-color touch screen display
6 speaker audio system
Bluetooth® hands-free phone and audio streaming capability

MAZDA CONNECT™ Infotainment System
- Multifunction Commander Control
- Infotainment system voice command
- Radio Broadcast Data System program information
- Aha™ internet radio integration
- Stitcher™ internet radio integration

Auxiliary-audio input jack
USB Audio input, 2 in front center console
Steering wheel-mounted audio controls

INSTRUMENTATION

Full-color active driving display
Electronic odometer
Trip computer

ENGINE

Engine type SKYACTIV®-G 1.5L DOHC S-VT gasoline engine with i-stop
Maximum power 81kW @ 6000 rpm / Horsepower 108.6 hp @ 6000 rpm
Maximum torque 141Nm @ 4000 rpm / Maximum torque 103.9 lb-ft @ 4000 rpm
Displacement (cc) 1,496
Bore x stroke (mm) 74.5 x 85.8
Compression ratio 13.0:1
Fuel System Advanced Direct Injection
Recommended fuel regular unleaded (91RON or higher) or E10
SKYACTIV-VEHICLE DYNAMICS with G-Vectoring Control

DRIVETRAIN

Type Front-wheel drive (FWD)
6-speed manual transmission SKYACTIV®-MT
6-speed automatic transmission SKYACTIV®-DRIVE  with manual-shift
i-stop Standard

Gear ratios (:1) 6 AT

1st 3.529
2nd 2.025
3rd 1.348
4th 1.000
5th 0.742
6th 0.594
Reverse 2.994
Final Drive 4.319

6 MT

1st 3.583
2nd 1.904
3rd 1.290
4th 0.972
5th 0.795
6th 0.645
Reverse 3.454
Final Drive 4.105

CHASSIS

Brakes 4-wheel disc
- Front 258 mm vented disc
- Rear 200 mm solid disc
- ABS 4-wheel, 4-channel with Electronic Brake Force Distribution and Brake Assist
Steering type Power rack-and-pinion with variable assist
Electronic Power Assist Steering (EPAS)
Turning circle diameter, curb-to-curb (m) 9.8m
Suspension 4-wheel independent
- Front MacPherson strut with stabilizer bar
- Rear Multilink with stabilizer bar

WEIGHTS & CAPACITIES

Curb weight (kg) 1,038 (MT)/1,053 (AT)
Fuel capacity (liters) 44

SAFETY

Advanced dual front air bags with passenger weight sensors (Mazda Advanced Restraint System)
Front seat-mounted side-impact air bags and side-impact air curtains
3-point safety belts for all seating positions
Headrests, adjustable - front & rear - all seating positions
Front safety-belt pretensioners with force limiters
Anti-lock Brake System (ABS) with Electronic Brake Force Distribution & Brake Assist
Hill Launch assist
Dynamic Stability Control (DSC) with Traction Control System (TCS)
Advanced Blind Spot Monitoring with Rear Cross Traffic Alert
Smart City Brake Support
Rearview camera
Side-impact door beams
Collapsible steering column
Engine-immobilizer antitheft system
Keyless remote panic button (on key fob)
Automatic door locks (speed-sensitive and transmission-sensitive)
LATCH child safety seat anchors & upper tethers
Child safety rear door locks
Rear parking sensors

BODY

Automatic on/off headlights
LED fog lights
LED daytime running lights
Rain-sensing variable-intermittent windshield wipers
Body-colored power and heated side mirrors with integrated turn signals roof-mounted "shark fin" antenna
Rear window wiper

WHEELS & TIRES

16 x 5.5 J aluminum alloy
185/60 R16
Temporary spare tire - T125/70 D15

EXTERIOR DIMENSIONS

Wheelbase (mm) 2,570
Track, front (mm) 1,495
Track, rear (mm) 1,485
Length (mm) 4,060
Width (mm) 1,695
Height (mm) 1,495
Minimum ground clearance, unladen (mm) 152

COMFORT & CONVENIENCE

Air conditioning climate control
Power windows with driver's one-touch-down/up feature
Cruise control with steering-wheel-mounted controls
Mazda Advanced Keyless Entry
Push button start
Tilt & telescopic steering column

STORAGE

Front cup holder
Front door storage pockets with bottle holders
Front passenger-side seatback pocket

SEATING & TRIM

5-passenger seating capacity
60/40 split fold-down rear seatback
Leather/cloth-trimmed seats
Carpet floor mats
Leather-wrapped steering wheel and shifter

AUDIO & INFOTAINMENT

7" full-color touch screen display
6 speaker audio system
Bluetooth® hands-free phone and audio streaming capability

MAZDA CONNECT™ Infotainment System
- Multifunction Commander Control
- Infotainment system voice command
- Radio Broadcast Data System program information
- Aha™ internet radio integration
- Stitcher™ internet radio integration

Auxiliary-audio input jack
USB Audio input, 2 in front center console
Steering wheel-mounted audio controls

INSTRUMENTATION

Full-color active driving display
Electronic odometer
Trip computer

ENGINE

Engine type SKYACTIV®-G 1.5L DOHC S-VT gasoline engine with i-stop
Maximum power 81kW @ 6000 rpm / Horsepower 108.6 hp @ 6000 rpm
Maximum torque 141Nm @ 4000 rpm / Maximum torque 103.9 lb-ft @ 4000 rpm
Displacement (cc) 1,496
Bore x stroke (mm) 74.5 x 85.8
Compression ratio 13.0:1
Fuel System Advanced Direct Injection
Recommended fuel regular unleaded (91RON or higher) or E10
SKYACTIV-VEHICLE DYNAMICS with G-Vectoring Control

DRIVETRAIN

Type Front-wheel drive (FWD)
6-speed manual transmission SKYACTIV®-MT 6-speed
6-speed automatic transmission SKYACTIV®-DRIVE with manual-shift
i-stop Standard

Gear ratios (:1) 6 AT

1st 3.529
2nd 2.025
3rd 1.348
4th 1.000
5th 0.742
6th 0.594
Reverse 2.994
Final Drive 4.319

6 MT

1st 3.583
2nd 1.904
3rd 1.290
4th 0.972
5th 0.795
6th 0.645
Reverse 3.454
Final Drive 4.105

CHASSIS

Brakes 4-wheel disc
- Front 258 mm vented disc
- Rear 200 mm solid disc
- ABS 4-wheel, 4-channel with Electronic Brake Force Distribution and Brake Assist
Steering type Power rack-and-pinion with variable assist
Electronic Power Assist Steering (EPAS)
Turning circle diameter, curb-to-curb (m) 9.8m
Suspension 4-wheel independent
- Front MacPherson strut with stabilizer bar
- Rear Multilink with stabilizer bar

WEIGHTS & CAPACITIES

Curb weight (kg) 1,038 (MT)/1,053 (AT)
Fuel capacity (liters) 44

SAFETY

Advanced dual front air bags with passenger weight sensors (Mazda Advanced Restraint System)
Front seat-mounted side-impact air bags and side-impact air curtains
3-point safety belts for all seating positions
Headrests, adjustable - front & rear - all seating positions
Front safety-belt pretensioners with force limiters
Anti-lock Brake System (ABS) with Electronic Brake Force Distribution & Brake Assist
Hill Launch assist
Dynamic Stability Control (DSC) with Traction Control System (TCS)
Advanced Blind Spot Monitoring with Rear Cross Traffic Alert
Smart City Brake Support
Rearview camera
Side-impact door beams
Collapsible steering column
Engine-immobilizer antitheft system
Keyless remote panic button (on key fob)
Automatic door locks (speed-sensitive and transmission-sensitive)
LATCH child safety seat anchors & upper tethers
Child safety rear door locks
Rear parking sensors
