BODY

LED headlights with auto on/off and auto height control
LED daytime running lights
LED combination taillights
LED grille accent lighting
LED fog lights
High Beam control
Adaptive Front Lighting System
Rain-sensing variable-intermittent windshield wipers
Windshield wiper de-icer
Intermittent rear wiper/washer
Chrome front, side and rear lower body molding
Body-colored power side mirrors with integrated LED turn signal lamps
Heated side mirrors
Body-colored door handles
Rear privacy glass
Aluminum roof rails in satin chrome finish
Dual exhaust outlets
Body-colored rear roof spoiler

WHEELS & TIRES

20 x 8.5 aluminum alloy wheels
P255/50 R20 all-season tires
Temporary spare tire - T155/90 D17

EXTERIOR DIMENSIONS

Wheelbase (mm) 2,928
Track, front (mm) 1,659
Track, rear (mm) 1,656
Length (mm) without front license plate holder 5,065
Width (mm) with/without wheel arch moldings 1,969/1961
Height (mm) up to roof, without sharkfin antenna 1,753/1,717
Minimum ground clearance, unladen (mm) 223.5

COMFORT & CONVENIENCE

Three-zone automatic climate control with pollen filter
Power sliding-glass moonroof with one-touch-open feature and interior sunshade
Power windows with driver’s one-touch down/up feature
Power door locks with speed sensing auto-locking
Front & rear door courtesy lamps
Auto-Dimming rearview mirror with HomeLink®
Mazda Radar Cruise Control with Stop & Go
Mazda Advanced Keyless Entry and Start System
Push Button Start
LED accent lighting for shifter area, door pockets, door pulls and window/door lock switches
Genuine aluminum interior trim
Genuine rosewood inlays – shifter surround and door switchgear
Tilt & telescopic steering column
Power rear lift gate with programmable height adjustment
Remote fuel-door release
2nd row retractable window sunshades

STORAGE

Overhead console with sunglasses holder
Front center console armrest with storage and 2 USB inputs
2nd row center armrest with integrated cup holders, storage and 2 USB inputs
Front and rear door bottle holderswith storage pockets/bins
Driver and front passenger seatback pockets
Cargo area with storage boxes and under-floor storage

SEATING & TRIM

7-passenger seating capacity
Power driver’s seat with power lumbar support and 2-position memory
Power front passenger seat
60/40 split fold-down and reclining 2nd-row seats with tilt and slide 3rd-row access
50/50 split fold-down 3rd-row seats
Heated front seats (3 levels)
Heated 2nd-row seats
Napa Leather-trimmed seats (1st and 2nd-row outboard seating positions)
Leather-wrapped steering wheel with unique stitching
Heated steering wheel
Leather-wrapped shift knob
Carpet floor mats

AUDIO & INFOTAINMENT

8" full-color touch screen display
Bose® Centerpoint® Surround Sound audio with AudioPilot® and 12 speakers
Bluetooth® hands-free phone and audio capability
Mazda Navigation System

MAZDA CONNECT™ Infotainment System
- Infotainment system voice command
- Multifunction Commander control
- Radio Broadcast Data System program information
- HD Radio™
- Aha™ internet radio integration
- Pandora® internet radio integration
- Stitcher™ internet radio integration
- SMS text message audio delivery and reply

Auxiliary-audio input jack
USB Audio input, 2 front and 2 rear
Steering wheel-mounted audio, phone and cruise controls

INSTRUMENTATION

Speedometer, tachometer and fuel gauge with white lettering
Active driving display with Traffic Sign Recognition
Ambient temperature & clock display
Multi-Information Display (MID) with Trip Computer

INTERIOR DIMENSIONS & CAPACITIES

Headroom, front/2nd-row/3rd-row (mm) 998/978/899
Shoulder room, front/2nd-row/3rd-row (mm) 1,471/1,476/1,349
Hip room, front/2nd-row/3rd-row (mm) 1,440/1,458/1,019
Legroom, front/2nd-row/3rd-row (mm) 1,041/1,001/754
EPA passenger volume (cu ft) 135.1
EPA cargo volume – rear seats up/3rd-row/2nd-row and 3rd-row folded (cu ft) 14.4/38.2/71.2

ENGINE

Engine type SKYACTIV®-G 2.5L Dynamic Pressure Turbo DHOC 16-valve 4-cylinder with VVT
Maximum power, 87 octane regular unleaded fuel 169.2 kW @ 5,000 rpm / Horsepower, 87 octane regular unleaded fuel 227 hp @ 5,000 rpm
Maximum power, 93 octane premium unleaded fuel 186.4 kW @ 5,000 rpm / Horsepower, 93 octane premium unleaded fuel 250 hp @ 5,000 rpm
Torque 420.3 Nm @ 2000 rpm / Torque 310 lb-ft @ 2000 rpm
Redline 6300 rpm
Displacement (cc) 2488
Bore x stroke (mm) 89.0 x 100.0
Compression ratio 10.5:1
Maximum intake boost pressure (psi) 17.4
Fuel System Advanced Direct Injection
Recommended fuel regular unleaded
Valvetrain Chain-driven dual overhead cams, 4 valves per cylinder with variable valve timing (VVT)
Ignition system direct coil-on-plug electronic ignition with iridium alloy platinum-tipped spark plugs
Engine block aluminum alloy
Cylinder head aluminum alloy
SKYACTIV-VEHICLE DYNAMICS with G-Vectoring Control

DRIVETRAIN

Type i-ACTIV AWD®
6-speed automatic transmission SKYACTIV®-DRIVE with manual-shift and sport mode

Gear ratios (:1)
1st 3.487
2nd 1.992
3rd 1.449
4th 1.000
5th 0.707
6th 0.600
Reverse 3.990
Final Drive 4.411

CHASSIS

Brakes 4-wheel disc, diagonal hydraulic
- Front 320-mm vented disc(FWD)
- Rear 325-mm solid discs
ABS 4-wheel, 4 channel with Electronic Brakeforce Distribution (EBD) and Brake Assist
Parking brake Electronic
Steering Type Power rack-and-pinion with variable assist
Power assist Electric Power Assist Steering (EPAS)
Overall steering ratio 17:6:1
Steering wheel turns, lock-to-lock 3.1
Turning circle diameter, curb-to-curb (m) 11.8
Suspension 4-wheel independent
- Front Macpherson strut with stabilizer bar
- Rear Multilink with stabilizer bar

WEIGHTS & CAPACITIES

Curb weight (kg) 1,978.1 (AWD)
Towing capacity (kg) 1,587.5
Fuel capacity (liters) 73.8 (AWD)

SAFETY

Advanced dual front air bags with seat belt-use, passenger weight sensors
Front side-impact air bags and side-impact air curtains with rollover protection
3-point seat belts for all seating positions
Front seat belt pretensioners with force limiters
Anti-lock Brake System with Electronic Brake Force Distribution & Brake Assist
Dynamic Stability Control (DSC) with Traction Control System (TCS)
Rearview camera
Roll Stability control
Hill Launch assist
Advanced Blind Spot Monitoring with Rear Cross Traffic Alert
Lane Keep assist
Lane Departure warning
Front parking sensors
Rear backup sensors
Smart City Brake Support
Smart Brake Support
Side-impact door beams
Engine-immobilizer antitheft system
Tire Pressure Monitoring System (TPMS)
LATCH 2nd-row seat child safety seat anchors & upper tethers anchors
Child safety rear door locks
